Parameters Dimensions Shaft Type Other
Model HW7-400 HW7-500 HW7-600 HW7-700 HW7-800
Displacement (ml/r)
Displacement 		404  511  594  683  779
Plunger Diameter (mm)
Plunger Diameter 		55  55  55  59  63
Plunger stroke (mm)
Plunger stroke 		34  43  50  50  50
Unit Torque (N.m/Mpa)
Theoric Specific Torque 		64  81  94  109  124
Rated Pressure (Mpa)
Rated Pressure 		21  21  21  21  21
Peak Pressure (Mpa)
Peak Pressure 		30  30  30  30  30
Rated Torque (N.m)
Rated Torque 		1348  1705  1982  2281  2601
Speed Range (r/min)
Speed Range 		5-500 5-500 5-500 4-400 4-300
Maximum Speed (r/min)
Max. Cont. Speed 		600  600  600  500  350
